Manufacturer, Supplier & Exporter of Stainless Steel 304 Globe Valve

SStainless Steel 304 Globe Valve is an essential industrial valve designed for precise throttling and flow regulation in various pipeline systems. Unlike gate valves that are best for on/off service, globe valves allow more accurate control over the flow rate, thanks to their perpendicular disc movement and constricted flow path. Made from ASTM A351 Grade CF8 (equivalent to SS 304), this valve material ensures excellent corrosion resistance, strength, and durability, especially in environments exposed to chemicals, moisture, and temperature variations.

SS 304 Globe Valves are widely used in sectors such as chemical processing, oil and gas, power plants, food processing, water treatment, and marine applications. Their corrosion resistance properties make them particularly suitable for clean or semi-aggressive fluids. These valves are manufactured in various end connections like flanged, socket weld, or threaded types and are available in pressure classes like 150, 300, and 600, suitable for medium to high-pressure services.

Riddhi Siddhi Impex, a reputed Indian manufacturer and domestic supplier, plays a significant role in providing high-quality Stainless Steel 304 Globe Valves across the country. With a commitment to industrial standards like API 602, BS 1873, and ASME B16.34, their globe valves are built with precision machining, rigorous pressure testing, and durable sealing components to ensure leak-proof performance and long operational life.

Being a domestic supplier, Riddhi Siddhi Impex has a wide distribution network that caters to several key industrial and urban centers. The company supplies SS 304 Globe Valves across Mumbai, Delhi, Bengaluru (Bangalore), Hyderabad, Chennai, Kolkata, Pune, Ahmedabad, Surat, Vadodara, Rajkot, Nagpur, Indore, Bhopal, Jaipur, Kanpur, Lucknow, Agra, Varanasi, Amritsar, Chandigarh, Mysuru, Udaipur, Jodhpur, Visakhapatnam, Coimbatore, Madurai, Kochi, Thiruvananthapuram, Mangalore, Nashik, Kolhapur, Chandrapur, Akola, Vilayat, Somnath, Dahej, Ankleshwar, Navsari, Valsad, Rajpipla, and more.

One of the key advantages of choosing SS 304 for globe valves is its hygienic properties and non-reactive nature, which is important in food, beverage, and pharmaceutical applications. Additionally, the valve’s ability to regulate flow with minimal seat wear makes it ideal for modulating services and applications requiring frequent operation.

Stainless Steel 304 Globe Valve

Specifications

Parameter	Details
Product	Globe Valve
Material	Stainless Steel 304 / ASTM A351 CF8
Valve Type	Globe Valve - Straight/Angle/Y Pattern
Size Range	1/2" to 24"
Pressure Rating	Class 150, 300, 600
End Connection	Flanged, Socket Weld, Threaded
Operation	Manual, Pneumatic, Electric Actuator
Standards	ASME B16.34, API 602, BS 1873

Chemical Composition (SS 304 / CF8)

Element	Content (%)
Carbon (C)	0.08 max
Manganese (Mn)	2.00 max
Silicon (Si)	1.00 max
Chromium (Cr)	18.0 – 20.0
Nickel (Ni)	8.0 – 11.0
Phosphorus (P)	0.045 max
Sulfur (S)	0.030 max

Mechanical Properties

Property	Value
Tensile Strength	485 MPa min
Yield Strength	170 MPa min
Elongation	30% min
Hardness	201 HB max

Dimension Chart (Sample - Class 150 Globe Valve)

Size (Inch)	Face-to-Face (mm)	Flange OD (mm)	Weight (kg)
2"	203	150	17
4"	229	228	30
6"	394	280	52
8"	419	343	78
12"	457	483	135

Equivalent Grades

Standard	Equivalent Grade
ASTM	A351 CF8
EN	1.4301
JIS	SUS 304
IS	30400

Equivalent Standards

Standard Body	Specification
ASTM	A351 CF8
ASME	B16.34
API	602
BS	1873

Other Types of Globe Valves

Valve Type	Description
Angle Pattern Globe Valve	Used where piping turns 90°, less pressure drop
Straight Pattern Globe Valve	Traditional inline design for normal flow
Y-Pattern Globe Valve	Reduced pressure loss, used in high-pressure lines
Pneumatic Globe Valve	Controlled by compressed air, ideal for automation
Electric Actuated Globe Valve	For remote control via electric actuator

Riddhi Siddhi Impex provides customization options in terms of valve size (½” to 24”), pressure rating, bonnet types (bolted, pressure seal), disc types (plug, ball, or composite), and actuator options (manual, pneumatic, or electric). Their valves are available in straight, angle, or Y-pattern body designs depending on the client’s space and flow requirements.

Frequently Asked Questions (FAQs)

Q1: What is the purpose of a Stainless Steel 304 Globe Valve?

A1: SS 304 Globe Valves are used for throttling and regulating flow in pipelines with good corrosion resistance.

Q2: Where are SS 304 Globe Valves commonly used?

A2: They are widely used in chemical, petrochemical, food, water treatment, and marine industries.

Q3: Does Riddhi Siddhi Impex supply these valves across India?

A3: Yes, they supply domestically to cities like Mumbai, Delhi, Bengaluru, Chennai, Hyderabad, Pune, and over 40+ others.

Q4: What sizes and pressure classes are available?

A4: Sizes range from ½” to 24” with pressure classes including 150, 300, and 600.
